MC10H116L - Motorola

MC10H116L Details

• Manufacturer Part Number:

  MC10H116L

• Part Life Cycle Code:

  Transferred

• Package Description:

  DIP-16

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Motorola Semiconductor Products

• Differential Output:

  YES

• High Level Input Current-Max:

  0.000095 A

• Input Characteristics:

  DIFFERENTIAL

• Interface IC Type:

  LINE RECEIVER

• Interface Standard:

  GENERAL PURPOSE

• JESD-30 Code:

  R-GDIP-T16

• JESD-609 Code:

  e0

• Length:

  19.49 mm

• Number of Functions:

  3

• Number of Terminals:

  16

• Operating Temperature-Max:

  75 °C

• Output Polarity:

  COMPLEMENTARY

• Package Body Material:

  CERAMIC

• Package Code:

  DIP

• Package Equivalence Code:

  DIP16,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• Receive Delay-Max:

  1.45 ns

• Receiver Number of Bits:

  3

• Seated Height-Max:

  5.08 mm

• Supply Current-Max:

  23 mA

• Surface Mount:

  NO

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Width:

  7.62 mm
