MC1496DR2G - onsemi

Description: Adjustable Gain and Signal Handling; Excellent Carrier Suppression –65 dB typ @ 0.5 MHz –50 dB typ @ 10 MHz; Balanced Inputs and Outputs; High Common Mode Rejection -85 dB typical

Download MC1496DR2G Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MC1496DR2G - onsemi PCB footprint - Small Outline Packages - Small Outline Packages - FST3125MTCX
click to zoom
3D Models
MC1496DR2G - onsemi  - 3D model - Small Outline Packages - FST3125MTCX
click to zoom

MC1496DR2G Details

  • Manufacturer Part Number:

    MC1496DR2G

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    SOIC-14 NB

  • Package Description:

    SOIC-14

  • Pin Count:

    14

  • Manufacturer Package Code:

    751A-03

  • Country Of Origin:

    Philippines

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    9 Weeks

  • Manufacturer:

    onsemi

  • Consumer IC Type:

    CONSUMER CIRCUIT

  • JESD-30 Code:

    R-PDSO-G14

  • JESD-609 Code:

    e3

  • Length:

    8.65 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    70 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.75 mm

  • Supply Voltage-Max (Vsup):

    12 V

  • Supply Voltage-Min (Vsup):

    12 V

  • Surface Mount:

    YES

  • Temperature Grade:

    COMMERCIAL

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3.9 mm

MC1496DR2G Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the MC1496DR2G is 5V to 15V, with a typical voltage of 12V.
  • To ensure stability, it's essential to follow proper PCB layout practices, use a stable power supply, and add decoupling capacitors close to the device. Additionally, ensure that the input and output impedances are matched to prevent oscillations.
  • The maximum power dissipation of the MC1496DR2G is 1.5W, and it's essential to ensure that the device is properly heat-sinked to prevent overheating.
  • No, the MC1496DR2G is not designed for switch-mode operation. It's intended for linear amplifier applications, and using it in a switch-mode configuration may lead to instability and reduced performance.
  • The choice of external components, such as resistors and capacitors, depends on the specific application and frequency range. Refer to the datasheet and application notes for guidance on selecting the correct components for your design.
