- Part Number MC1596G
- Manufacturer Motorola
- Pin Count 10
- Part Category Integrated Circuit
- Package Category Other
- Footprint Name Other - MC1596G
- Released Date Oct 25, 2023
- Last Modified Date Nov 17, 2023 6:28 AM UTC
- Pinout / Pin List Click Here (Member Only)
MC1596G Details
-
Manufacturer Part Number:
MC1596G
-
Part Life Cycle Code:
Obsolete
-
Package Description:
METAL PACKAGE-10
-
HTS Code:
8542.39.00.60
-
Manufacturer:
Motorola Semiconductor Products
-
YTEOL:
0
-
Consumer IC Type:
CONSUMER CIRCUIT
-
JESD-30 Code:
O-MBCY-W10
-
JESD-609 Code:
e0
-
Number of Functions:
1
-
Number of Terminals:
10
MC1596G Frequently Asked Questions (FAQs)
-
The recommended operating voltage range for the MC1596G is 5V to 15V, with a typical voltage of 12V.
-
To ensure stable operation in high-temperature environments, it's recommended to use a heat sink and ensure good thermal conductivity between the device and the heat sink. Additionally, reducing the power supply voltage and minimizing the current drawn from the device can help reduce heat generation.
-
The maximum power dissipation of the MC1596G is 1.5W, and it's recommended to keep the power dissipation below 1W for reliable operation.
-
To protect the MC1596G from ESD, it's recommended to handle the device with an anti-static wrist strap or mat, and to use ESD-protected packaging and storage materials.
-
Yes, the MC1596G can be used in switching power supply applications, but it's essential to ensure that the device is properly bypassed and filtered to prevent high-frequency noise and voltage spikes from affecting its operation.
