MCP2517FD-H/JHA - Microchip

MCP2517FD-H/JHA Details

• Manufacturer Part Number:

  MCP2517FD-H/JHA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  VDFN-14

• Pin Count:

  14

• Manufacturer Package Code:

  VDFN-14

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Factory Lead Time:

  9 Weeks

• Date Of Intro:

  2017-08-24

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  19

• Boundary Scan:

  NO

• Bus Compatibility:

  SPI

• Clock Frequency-Max:

  40 MHz

• Communication Protocol:

  CAN FD

• Data Transfer Rate-Max:

  1 MBps

• JESD-30 Code:

  R-PDSO-N14

• JESD-609 Code:

  e3

• Length:

  4.5 mm

• Low Power Mode:

  YES

• Number of I/O Lines:

  2

• Number of Serial I/Os:

  1

• Number of Terminals:

  14

• On Chip Data RAM Width:

  8

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Peak Reflow Temperature (Cel):

  260

• RAM (words):

  2048

• Screening Level:

  TS 16949

• Seated Height-Max:

  0.9 mm

• Supply Current-Max:

  20 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  2.7 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  3 mm

• uPs/uCs/Peripheral ICs Type:

  SERIAL IO/COMMUNICATION CONTROLLER, LAN
