MCP33111D-10-I/MS - Microchip

MCP33111D-10-I/MS Details

• Manufacturer Part Number:

  MCP33111D-10-I/MS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Pin Count:

  10

• Manufacturer Package Code:

  MSOP-10

• Country Of Origin:

  Thailand

• HTS Code:

  8542.39.00.30

• Factory Lead Time:

  7 Weeks

• Date Of Intro:

  2018-03-09

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  3

• Analog Input Voltage-Max:

  5 V

• Analog Input Voltage-Min:

  -5 V

• Conversion Time-Max:

  0.75 µs

• Converter Type:

  ADC, FLASH/SUCCESSIVE APPROXIMATION

• JESD-30 Code:

  S-PDSO-G10

• Length:

  3 mm

• Linearity Error-Max (EL):

  0.0003%

• Number of Analog In Channels:

  1

• Number of Bits:

  12

• Number of Functions:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  2'S COMPLEMENT BINARY

• Output Format:

  SERIAL

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSSOP

• Package Equivalence Code:

  TSSOP10,.19,20

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

• Sample Rate:

  1 MHz

• Seated Height-Max:

  1.1 mm

• Supply Current-Max:

  2.4 mA

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Width:

  3 mm
