MCP79520-I/MS - Microchip

MCP79520-I/MS Details

• Manufacturer Part Number:

  MCP79520-I/MS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  TSSOP, TSSOP10,.19,20

• Pin Count:

  10

• Manufacturer Package Code:

  MSOP-10

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Thailand

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  13

• Additional Feature:

  ALSO OPEARTES AT 1.8V MIN SUPPLY AT 3MHZ CLOCK FREQ

• Clock Frequency-Max:

  0.032 MHz

• Information Access Method:

  SERIAL(SPI)

• Interrupt Capability:

  Y

• JESD-30 Code:

  S-PDSO-G10

• JESD-609 Code:

  e3

• Length:

  3 mm

• Moisture Sensitivity Level:

  2

• Number of Terminals:

  10

• On Chip Data RAM Width:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSSOP

• Package Equivalence Code:

  TSSOP10,.19,20

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

• Peak Reflow Temperature (Cel):

  260

• RAM (words):

  64

• Screening Level:

  TS 16949

• Seated Height-Max:

  1.1 mm

• Supply Current-Max:

  5 mA

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  1.8 V

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Time-Min:

  1/100 SECOND

• Time@Peak Reflow Temperature-Max (s):

  40

• Volatile:

  NO

• Width:

  3 mm

• uPs/uCs/Peripheral ICs Type:

  TIMER, REAL TIME CLOCK
