MD-80SG - Same Sky

MD-80SG Details

• Manufacturer Part Number:

  MD-80SG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.20

• Manufacturer:

  Same Sky

• YTEOL:

  0

• Board Mounting Option:

  SOLDER HOLDING FLANGE

• Body Breadth:

  0.51 inch

• Body Depth:

  0.52 inch

• Body Length:

  0.56 inch

• Body/Shell Style:

  JACK

• Connector Type:

  MINI DIN CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT APPLICABLE

• Contact Resistance:

  30 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  250VAC V

• Durability:

  1000 Cycles

• EMI Shielded:

  YES

• Insertion Force-Max:

  44.1 N

• Insulation Resistance:

  50000000 Ω

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  2 A

• Reference Standard:

  UL

• Terminal Length:

  0.14 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  8
