MGDDI-60-R-C - Gaia Converter

MGDDI-60-R-C Details

• Manufacturer Part Number:

  MGDDI-60-R-C

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT, METAL, PACKAGE-17

• Country Of Origin:

  France

• ECCN Code:

  EAR99

• Manufacturer:

  GAIA Converter Inc

• YTEOL:

  8

• Additional Feature:

  ADDITIONAL 5V OUTPUT AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  91%

• Input Voltage-Max:

  160 V

• Input Voltage-Min:

  12 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-MDMA-T17

• Length:

  72.7 mm

• Line Regulation-Max:

  1.5%

• Load Regulation-Max:

  1.5%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  17

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  5 A

• Output Voltage-Max:

  5.5 V

• Output Voltage-Min:

  4 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  METAL

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,17LEAD,2.8

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL

• Ripple Voltage (Main Out):

  70.7 Vrms

• Seated Height-Max:

  12.7 mm

• Surface Mount:

  NO

• Switching Frequency-Max:

  270 kHz

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  GOLD FLASH OVER NICKEL

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  5.08 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  50 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.03 s

• Width:

  47.9 mm
