MIC2782ELYCS-TR - Microchip

Description: Supervisory Circuits Dual Input Push Button Reset IC with RESET and ANDOUT Outputs

Download MIC2782ELYCS-TR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MIC2782ELYCS-TR - Microchip - PCB symbol
click to zoom
PCB Footprints
MIC2782ELYCS-TR - Microchip PCB footprint - BGA - BGA - 6-Bump,0.4mm pitch 0.8x1.2mm WLCSP(CS)
click to zoom
3D Models
MIC2782ELYCS-TR - Microchip - 3D model - BGA - 6-Bump,0.4mm pitch 0.8x1.2mm WLCSP(CS)
click to zoom

MIC2782ELYCS-TR Details

  • Manufacturer Part Number:

    MIC2782ELYCS-TR

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Pin Count:

    6

  • Manufacturer Package Code:

    WLCSP-6

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Factory Lead Time:

    13 Weeks

  • Manufacturer:

    Microchip Technology Inc

  • YTEOL:

    3

  • Additional Feature:

    BAT BUP SW:N;MNL RST:Y;OV DET:N;PW FL IP:N;PW FL IO:N;PW FL OP:N;PRG RST DLY:N;UV DET:N;WD:N;WWD:N

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    VOLTAGE SUPERVISOR/RESET IC

  • JESD-30 Code:

    R-PBGA-B6

  • Length:

    1.2 mm

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    6

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    VFBGA

  • Package Equivalence Code:

    BGA6,2X3,16

  • Package Shape:

    RECTANGULAR

  • Package Style:

    GRID ARRAY, VERY THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    0.575 mm

  • Supply Voltage-Max (Vsup):

    5.5 V

  • Supply Voltage-Min (Vsup):

    1.5 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.4 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    10

  • Width:

    0.8 mm

MIC2782ELYCS-TR Frequently Asked Questions (FAQs)

  • A good PCB layout for optimal thermal performance involves placing the MIC2782ELYCS-TR near a thermal pad or a heat sink, and ensuring good copper pour and thermal vias to dissipate heat efficiently.
  • To ensure a stable and regulated output voltage, make sure to use a suitable output capacitor with a low ESR, and follow the recommended layout and decoupling guidelines in the datasheet.
  • The maximum input voltage that can be applied to the MIC2782ELYCS-TR is 28V, but it's recommended to operate within the specified input voltage range of 4.5V to 18V for optimal performance and reliability.
  • The MIC2782ELYCS-TR is rated for operation up to 125°C, but it's essential to consider the thermal derating and ensure proper heat sinking and cooling to prevent overheating and ensure reliable operation.
  • To troubleshoot issues with the MIC2782ELYCS-TR, start by checking the input voltage, output voltage, and current consumption. Verify that the PCB layout and component selection meet the recommended guidelines. Use oscilloscopes and thermal imaging tools to identify any anomalies or hotspots.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

MIC2782ELYCS-TR Overview

Use the download button to access the MIC2782ELYCS-TR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like MIC27, or try a keyword search, such as Power Management Circuits

About Microchip

Microchip Technology Inc. is a leading manufacturer of microcontrollers and semiconductor devices for a wide range of applications in the aerospace, automotive, consumer electronics, industrial, and medical industries. Alongside a comprehensive product portfolio, Microchip Technology Inc. also provides easy-to-use development tools that enable engineers to create optimal designs quickly with minimal iterations to reduce risk while lowering total system costs to market. Headquartered in Chandler, Arizona, th
