MIXG120W1200TEH - LITTELFUSE

MIXG120W1200TEH Details

• Manufacturer Part Number:

  MIXG120W1200TEH

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  0

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  186 A

• Collector-Emitter Voltage-Max:

  1200 V

• Configuration:

  BRIDGE, 6 ELEMENTS WITH BUILT-IN DIODE AND THERMISTOR

• Gate-Emitter Thr Voltage-Max:

  7 V

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-XUFM-P35

• Number of Elements:

  6

• Number of Terminals:

  35

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  625 W

• Reference Standard:

  UL RECOGNIZED

• Surface Mount:

  NO

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UPPER

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  330 ns

• Turn-on Time-Nom (ton):

  120 ns

• VCEsat-Max:

  2 V
