MKP1839468134HQ - Vishay

Description: Film Capacitors .68uF 1600volts 5% High Quality Cap.

Download MKP1839468134HQ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MKP1839468134HQ - Vishay - PCB symbol
click to zoom
PCB Footprints
MKP1839468134HQ - Vishay PCB footprint - Other - Other - MKP1839468134HQ-4
click to zoom

MKP1839468134HQ Details

  • Manufacturer Part Number:

    MKP1839468134HQ

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    AXIAL LEADED

  • Reach Compliance Code:

    Compliant

  • ECCN Code:

    EAR99

  • HTS Code:

    8532.25.00.60

  • Factory Lead Time:

    10 Weeks

  • Manufacturer:

    Vishay Intertechnologies

  • YTEOL:

    7

  • Capacitance:

    0.68 µF

  • Capacitor Type:

    FILM CAPACITOR

  • Diameter:

    28 mm

  • Dielectric Material:

    POLYPROPYLENE

  • JESD-609 Code:

    e3

  • Length:

    31.5 mm

  • Mounting Feature:

    THROUGH HOLE MOUNT

  • Negative Tolerance:

    5%

  • Number of Terminals:

    2

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Shape:

    TUBULAR PACKAGE

  • Package Style:

    Axial

  • Packing Method:

    BULK

  • Positive Tolerance:

    5%

  • Rated (AC) Voltage (URac):

    450 V

  • Rated (DC) Voltage (URdc):

    1600 V

  • Reference Standard:

    IEC60384-17

  • Surface Mount:

    NO

  • Terminal Finish:

    Tin (Sn)

  • Terminal Shape:

    WIRE

MKP1839468134HQ Frequently Asked Questions (FAQs)

  • The recommended soldering temperature for MKP1839468134HQ is between 250°C to 260°C, with a maximum exposure time of 3 seconds.
  • Yes, the MKP1839468134HQ capacitor is RoHS (Restriction of Hazardous Substances) compliant, meaning it meets the EU's directive on the restriction of certain hazardous substances in electrical and electronic equipment.
  • The MSL of MKP1839468134HQ is MSL 2, which means it can be exposed to a maximum of 30°C and 60% relative humidity for 1 week before soldering.
  • While the MKP1839468134HQ capacitor is designed to withstand normal vibration, it's not specifically designed for high-vibration applications. For such applications, it's recommended to consult with Vishay's application engineers or consider using a capacitor with specific vibration-resistant design.
  • The recommended storage condition for MKP1839468134HQ is in a dry, cool place with a temperature range of 10°C to 30°C and relative humidity below 60%.
