The recommended oscillator crystal frequency for the ML51EB9AE is 12 MHz or 24 MHz, depending on the application and clock speed requirements.
The BOD on the ML51EB9AE can be configured through the BODCR register. The BOD voltage level can be set to 2.0V, 2.5V, 3.0V, or 3.5V, and the BOD reset delay can be set to 2ms, 4ms, or 6ms.
The maximum current that can be sourced or sunk by the GPIO pins on the ML51EB9AE is 20mA per pin, with a total current limit of 100mA for all GPIO pins combined.
The UART on the ML51EB9AE can be used by configuring the UART registers (UARTCR, UARTSR, UARTTHR, and UARTRBR) and enabling the UART clock. The UART baud rate can be set to a range of values from 50 bps to 115200 bps.
The power consumption of the ML51EB9AE varies depending on the operating mode. In active mode, the typical current consumption is around 2mA at 5V and 12MHz clock frequency. In idle mode, the typical current consumption is around 0.5mA at 5V and 12MHz clock frequency. In power-down mode, the typical current consumption is around 10uA at 5V.
