ML5810ATDZ87FL - ROHM Semiconductor

ML5810ATDZ87FL Details

• Manufacturer Part Number:

  ML5810ATDZ87FL

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  TSSOP-20

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  6

• High Side Driver:

  YES

• Input Characteristics:

  STANDARD

• Interface IC Type:

  BUFFER OR INVERTER BASED MOSFET DRIVER

• JESD-30 Code:

  R-PDSO-G20

• Length:

  6.5 mm

• Number of Functions:

  1

• Number of Terminals:

  20

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Peak Current Limit-Nom:

  0.02 A

• Output Polarity:

  TRUE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSSOP

• Package Equivalence Code:

  TSSOP20,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

• Seated Height-Max:

  1.1 mm

• Supply Current-Max:

  0.48 mA

• Supply Voltage-Max:

  64 V

• Supply Voltage-Min:

  6.5 V

• Supply Voltage-Nom:

  50 V

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Turn-off Time:

  70 µs

• Turn-on Time:

  350 µs

• Width:

  4.4 mm
