MLX90817KXE-DBH-008-RE - Melexis

MLX90817KXE-DBH-008-RE Details

• Manufacturer Part Number:

  MLX90817KXE-DBH-008-RE

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Manufacturer:

  Melexis Microelectronic Integrated Systems

• YTEOL:

  7

• Accuracy-Max (%):

  1.25%

• Additional Feature:

  SENSITIVITY OF 18 MV/V/BAR

• Body Breadth:

  4 mm

• Body Height:

  2.43 mm

• Body Length or Diameter:

  5 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Bits:

  16

• Operating Current-Max:

  10 mA

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Range:

  0.40-4.65V

• Output Type:

  ANALOG VOLTAGE

• Package Shape/Style:

  RECTANGULAR

• Port Type:

  HOLE

• Pressure Range-Max:

  16.68 Psi

• Pressure Range-Min:

  1.45 Psi

• Pressure Sensing Mode:

  ABSOLUTE

• Response Time:

  1000 µs

• Sensors/Transducers Type:

  PRESSURE SENSOR,PIEZORESISTIVE

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Surface Mount:

  YES

• Termination Type:

  SOLDER
