MN3-102 - Panasonic

Description: Clock Generator Driver/Driver for MN3200 Series BBD MN3 1 02 MN3102 CMOS CLOCK GENERATOR/DRIVER FOR LOW VOLTAGE OPERATION BBD ■ General description The MN3102 is a CMOS LSI generating two phase clock signal of low output impedance necessary to drive MN3200 series low voltage operation BBD. VGG power supply circuit is built-in exclusively used for the MN3200 series BBD* and most suitable VGG voltage can be obtained when the MN3102 is used with the same supply voltage as BBD. Self-oscillation is enabled
