MP5061GQV-Z - Monolithic Power Systems (MPS)

Description: Hot Swap Voltage Controllers 4.5V to 28V Current-Limit Switch with Low RDS(ON), Current Monitoring, and Soft Start

Download MP5061GQV-Z Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MP5061GQV-Z - Monolithic Power Systems (MPS) - PCB symbol
click to zoom
PCB Footprints
MP5061GQV-Z - Monolithic Power Systems (MPS) PCB footprint - Other - Other - QFN-22 (3mmx5mm)
click to zoom
3D Models
MP5061GQV-Z - Monolithic Power Systems (MPS) - 3D model - Other - QFN-22 (3mmx5mm)
click to zoom

MP5061GQV-Z Details

  • Manufacturer Part Number:

    MP5061GQV-Z

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    QFN-22

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Monolithic Power Systems

  • YTEOL:

    7

  • Additional Feature:

    CURRENT LIMIT:12.5A; THERMAL SHUTDOWN:167C; ADJUSTABLE CURRENT LIMIT

  • Adjustable Threshold:

    YES

  • Analog IC - Other Type:

    LOAD SWITCH

  • JESD-30 Code:

    R-PQCC-N22

  • Length:

    5 mm

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    22

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    VQCCN

  • Package Equivalence Code:

    LCC22,.12X.2,20

  • Package Shape:

    RECTANGULAR

  • Package Style:

    CHIP CARRIER, VERY THIN PROFILE

  • Seated Height-Max:

    1 mm

  • Supply Voltage-Max (Vsup):

    28 V

  • Supply Voltage-Min (Vsup):

    4.5 V

  • Supply Voltage-Nom (Vsup):

    12 V

  • Surface Mount:

    YES

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Threshold Voltage-Nom:

    3.8

  • Width:

    3 mm

MP5061GQV-Z Frequently Asked Questions (FAQs)

  • The maximum input voltage that can be applied to the MP5061GQV-Z is 24V, but it's recommended to keep it below 20V for reliable operation.
  • To ensure stability, it's recommended to use a minimum output capacitance of 10uF with an ESR of 1ohm or less, and to keep the output voltage within the specified range of 0.8V to 15V.
  • The maximum output current that the MP5061GQV-Z can deliver is 6A, but it's recommended to keep it below 5A for reliable operation and to avoid overheating.
  • To protect the MP5061GQV-Z from overheating, it's recommended to provide adequate heat sinking, keep the ambient temperature below 85°C, and avoid operating the device at maximum output current for extended periods.
  • Yes, the MP5061GQV-Z is suitable for high-reliability applications, but it's recommended to follow proper design and manufacturing guidelines, and to perform thorough testing and validation to ensure the device meets the required reliability standards.

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

MP5061GQV-Z Overview

Use the download button to access the MP5061GQV-Z schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like MP506, or try a keyword search, such as Power Management Circuits
