MP6540HGU-A-Z - Monolithic Power Systems (MPS)

Description: Motor / Motion / Ignition Controllers & Drivers 50V 5A Three-Phase Power Stage with HS & LS inputs.

Download MP6540HGU-A-Z Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MP6540HGU-A-Z - Monolithic Power Systems (MPS) PCB footprint - Other - Other - QFN-26 (5mmx5mm)_1
click to zoom
3D Models
MP6540HGU-A-Z - Monolithic Power Systems (MPS)  - 3D model - Other - QFN-26 (5mmx5mm)_1
click to zoom

MP6540HGU-A-Z Details

  • Manufacturer Part Number:

    MP6540HGU-A-Z

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    24 Weeks

  • Date Of Intro:

    2020-07-16

  • Manufacturer:

    Monolithic Power Systems

  • YTEOL:

    8

  • Analog IC - Other Type:

    3-PHASE BRUSHLESS DC MOTOR CONTROLLER

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    2

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Matte Tin (Sn)

  • Time@Peak Reflow Temperature-Max (s):

    30

MP6540HGU-A-Z Frequently Asked Questions (FAQs)

  • A good PCB layout for the MP6540HGU-A-Z should prioritize thermal dissipation. Place the device near a thermal pad or a heat sink, and ensure good airflow around the component. Use a 2-layer or 4-layer PCB with a solid ground plane to reduce thermal resistance. Keep the device away from other heat sources and ensure a minimum of 1mm clearance around the package.
  • To optimize output voltage accuracy, ensure that the input voltage is within the recommended range (4.5V to 18V). Use a high-precision voltage reference, such as a 0.5% or better resistor divider network, to set the output voltage. Additionally, minimize noise and ripple on the input voltage and output voltage lines.
  • A low-ESR ceramic capacitor (X5R or X7R dielectric) with a value of 4.7uF to 10uF is recommended for the input capacitor. This helps to filter out high-frequency noise and ensures stable operation.
  • To ensure stability, follow the recommended PCB layout and component placement guidelines. Use a low-ESR output capacitor (10uF to 22uF) and a small ceramic capacitor (100nF to 1uF) in parallel to filter out high-frequency noise. Avoid using electrolytic capacitors, which can cause oscillations.
  • The MP6540HGU-A-Z can deliver up to 4A of output current. However, the actual output current capability depends on the input voltage, output voltage, and thermal conditions. Ensure that the device is operated within the recommended operating conditions to avoid overheating and damage.
