MP6551GQB-Z - Monolithic Power Systems (MPS)

Description: Motor / Motion / Ignition Controllers & Drivers 2.5V -14V, 5A H-bridge motor driver

Download MP6551GQB-Z Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MP6551GQB-Z - Monolithic Power Systems (MPS) PCB footprint - Other - Other - QFN-14 (2.5mmx3mm)
click to zoom
3D Models
MP6551GQB-Z - Monolithic Power Systems (MPS)  - 3D model - Other - QFN-14 (2.5mmx3mm)
click to zoom

MP6551GQB-Z Details

  • Manufacturer Part Number:

    MP6551GQB-Z

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    24 Weeks

  • Manufacturer:

    Monolithic Power Systems

  • YTEOL:

    8

  • Analog IC - Other Type:

    HALF BRIDGE BRUSH DC MOTOR CONTROLLER

MP6551GQB-Z Frequently Asked Questions (FAQs)

  • The maximum junction temperature (TJ) that the MP6551GQB-Z can operate at is 150°C. However, it's recommended to keep the junction temperature below 125°C for optimal performance and reliability.
  • Yes, the MP6551GQB-Z is designed to operate in high-vibration environments. However, it's essential to ensure that the device is properly mounted and secured to prevent mechanical stress and damage.
  • To optimize the layout and placement of the MP6551GQB-Z for best thermal performance, it's recommended to follow the guidelines provided in the datasheet, including keeping the device away from heat sources, using thermal vias, and ensuring good airflow around the device.
  • The recommended input capacitor value and type for the MP6551GQB-Z is a 10uF to 22uF X5R or X7R ceramic capacitor with a voltage rating of 25V or higher. This helps to filter out noise and ensure stable operation.
  • Yes, the MP6551GQB-Z is designed to meet the requirements of various EMI standards, including CISPR 25 and FCC Part 15. However, it's essential to follow proper PCB layout and design practices to ensure optimal EMI performance.
