MPM3570EGLD - Monolithic Power Systems (MPS)

MPM3570EGLD Details

• Manufacturer Part Number:

  MPM3570EGLD

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LGA-8

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  24 Weeks

• Date Of Intro:

  2019-04-08

• Manufacturer:

  Monolithic Power Systems

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  CURRENT-MODE

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  S-XDMA-N8

• Length:

  10 mm

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.3 A

• Output Voltage-Max:

  12 V

• Output Voltage-Min:

  1 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  SQUARE

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Seated Height-Max:

  4.35 mm

• Supply Current-Max (Isup):

  110 mA

• Surface Mount:

  YES

• Switcher Configuration:

  BUCK

• Switching Frequency-Max:

  165 kHz

• Technology:

  HYBRID

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  2.7 mm

• Terminal Position:

  DUAL

• Width:

  10 mm
