MS5536-CNJU - TE Connectivity

MS5536-CNJU Details

• Manufacturer Part Number:

  MS5536-CNJU

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-14

• Manufacturer:

  TE Connectivity

• YTEOL:

  7

• Additional Feature:

  Port Diameter = 3 MM and Port Height = 4.9 MM

• Body Breadth:

  10.16 mm

• Body Height:

  3.2 mm

• Body Length or Diameter:

  13 mm

• Housing:

  PLASTIC

• Mounting Feature:

  SURFACE MOUNT

• Number of Bits:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Interface Type:

  3-WIRE SERIAL INTERFACE

• Output Range:

  0.60-2.40V

• Output Type:

  DIGITAL VOLTAGE

• Package Shape/Style:

  RECTANGULAR

• Port Type:

  HOLE/STRAIGHT

• Pressure Range-Max:

  5.8 Psi

• Pressure Range-Min:

  -14.5 Psi

• Pressure Sensing Mode:

  GAGE

• Response Time:

  0.2 µs

• Sensors/Transducers Type:

  PRESSURE SENSOR,PIEZORESISTIVE

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  2.2 V

• Surface Mount:

  YES

• Termination Type:

  SOLDER
