MSM54C865-10ZS - LAPIS SEMICONDUCTOR

MSM54C865-10ZS Details

• Manufacturer Part Number:

  MSM54C865-10ZS

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  ZIP

• Package Description:

  0.475 INCH, 1.27 MM PITCH, PLASTIC, ZIP-40

• Pin Count:

  40

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.02

• Manufacturer:

  LAPIS Semiconductor Co Ltd

• YTEOL:

  0

• Access Mode:

  FAST PAGE

• Access Time-Max:

  100 ns

• Additional Feature:

  RAS ONLY/CAS BEFORE RAS/HIDDEN REFRESH

• JESD-30 Code:

  R-PDIP-T40

• Length:

  51.2 mm

• Memory Density:

  524288 bit

• Memory IC Type:

  FAST PAGE DRAM

• Memory Width:

  8

• Number of Functions:

  1

• Number of Ports:

  2

• Number of Terminals:

  40

• Number of Words:

  65536 words

• Number of Words Code:

  64000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  70 °C

• Organization:

  64KX8

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  ZIP40,.1

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  12.07 mm

• Standby Current-Max:

  0.04 A

• Supply Current-Max:

  0.1 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  4.5 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  2.8 mm
