MSP430G2221IPW4Q1 - Texas Instruments

Description: Texas Instruments MSP430G2221IPW4Q1, 16bit MSP430 Microcontroller, 16MHz, 2 kB Flash, 14-Pin TSSOP

Download MSP430G2221IPW4Q1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MSP430G2221IPW4Q1 - Texas Instruments PCB footprint - Small Outline Packages - Small Outline Packages - PW (R-PDSO-G14)
click to zoom
3D Models
MSP430G2221IPW4Q1 - Texas Instruments  - 3D model - Small Outline Packages - PW (R-PDSO-G14)
click to zoom

MSP430G2221IPW4Q1 Details

  • Manufacturer Part Number:

    MSP430G2221IPW4Q1

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    TSSOP

  • Package Description:

    TSSOP, TSSOP14,.25

  • Pin Count:

    14

  • Reach Compliance Code:

    Unknown

  • HTS Code:

    8542.31.00.01

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    0

  • Has ADC:

    YES

  • Additional Feature:

    ALSO OPERATES AT 1.8V MINIMUM SUPPLY AT 6 MHZ

  • Bit Size:

    16

  • CPU Family:

    MSP430

  • Clock Frequency-Max:

    16 MHz

  • DAC Channels:

    NO

  • DMA Channels:

    YES

  • JESD-30 Code:

    R-PDSO-G14

  • Length:

    5 mm

  • Number of Terminals:

    14

  • On Chip Program ROM Width:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • PWM Channels:

    YES

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSSOP

  • Package Equivalence Code:

    TSSOP14,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

  • Qualification Status:

    Not Qualified

  • RAM (bytes):

    128

  • ROM (words):

    2048

  • ROM Programmability:

    FLASH

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.2 mm

  • Speed:

    16 MHz

  • Supply Current-Max:

    0.37 mA

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    4.4 mm

  • uPs/uCs/Peripheral ICs Type:

    MICROCONTROLLER, RISC
