MSWA2-50+ - Mini-Circuits

MSWA2-50+ Details

• Manufacturer Part Number:

  MSWA2-50+

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  QFN-12

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• YTEOL:

  6.3

• Additional Feature:

  HIGH ISOLATION

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  31 dBm

• Insertion Loss-Max:

  2.4 dB

• Isolation-Min:

  23 dB

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Frequency-Max:

  5000 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  LCC12,.12SQ,20

• Packing Method:

  TR, 7 INCH

• Port Termination:

  ABSORPTIVE

• RF/Microwave Device Type:

  SPDT

• Surface Mount:

  YES

• Technology:

  GAAS

• VSWR-Max:

  1.09
