MT25TL01GHBB8E12-0AAT - Micron

Description: NOR Flash Serial 3.3V 1G-bit 64M x 16 Automotive 24-Pin TBGA T/R/Tray

Download MT25TL01GHBB8E12-0AAT Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MT25TL01GHBB8E12-0AAT - Micron PCB footprint - BGA - BGA - 24-Ball T-PBGA (5 x 5 ball grid array) – 6mm x 8m
click to zoom
3D Models
MT25TL01GHBB8E12-0AAT - Micron  - 3D model - BGA - 24-Ball T-PBGA (5 x 5 ball grid array) – 6mm x 8m
click to zoom

MT25TL01GHBB8E12-0AAT Details

  • Manufacturer Part Number:

    MT25TL01GHBB8E12-0AAT

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    End Of Life

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.32.00.51

  • Factory Lead Time:

    10 Weeks

  • Date Of Intro:

    2017-07-28

  • Manufacturer:

    Micron Technology Inc

  • YTEOL:

    1

  • Memory IC Type:

    FLASH

MT25TL01GHBB8E12-0AAT Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the MT25TL01GHBB8E12-0AAT is -40°C to 105°C, as specified in the datasheet. However, it's recommended to operate the device within the industrial temperature range of -40°C to 85°C for optimal performance and reliability.
  • The MT25TL01GHBB8E12-0AAT requires a specific power-up and power-down sequence to ensure proper operation. It's recommended to follow the power-up sequence of VCC first, then VPP, and finally CLK. For power-down, the sequence should be reversed. Additionally, ensure that the power supply voltage is stable and within the recommended range before accessing the device.
  • The MT25TL01GHBB8E12-0AAT supports clock frequencies up to 166 MHz. However, the recommended clock frequency is 133 MHz to ensure optimal performance and minimize power consumption. It's essential to consult the datasheet for specific clock frequency requirements and limitations.
  • The MT25TL01GHBB8E12-0AAT provides various error detection and correction mechanisms, such as ECC and CRC. It's essential to implement error handling mechanisms in your design to detect and correct errors. Additionally, consult the datasheet for specific guidance on handling exceptions and errors during device operation.
  • The MT25TL01GHBB8E12-0AAT has specific layout and routing requirements to ensure signal integrity and minimize noise. It's recommended to follow the guidelines provided in the datasheet and application notes for optimal layout and routing. Additionally, consider using simulation tools to validate your design and ensure compliance with the device's requirements.
