MT35XU02GCBA1G12-0SIT - Micron

Description: NOR Flash SPI FLASH NOR SLC 256MX8 TBGA QDP

Download MT35XU02GCBA1G12-0SIT Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MT35XU02GCBA1G12-0SIT - Micron PCB footprint - BGA - BGA - 24-Ball T-BGA, 5 x 5
click to zoom
3D Models
MT35XU02GCBA1G12-0SIT - Micron  - 3D model - BGA - 24-Ball T-BGA, 5 x 5
click to zoom

MT35XU02GCBA1G12-0SIT Details

  • Manufacturer Part Number:

    MT35XU02GCBA1G12-0SIT

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    End Of Life

  • Package Description:

    TBGA-24

  • Country Of Origin:

    Mainland China, Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.32.00.51

  • Factory Lead Time:

    10 Weeks

  • Manufacturer:

    Micron Technology Inc

  • YTEOL:

    0

  • Clock Frequency-Max (fCLK):

    166 MHz

  • JESD-30 Code:

    R-PBGA-B24

  • JESD-609 Code:

    e1

  • Length:

    8 mm

  • Memory Density:

    2147483648 bit

  • Memory IC Type:

    FLASH

  • Memory Width:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    24

  • Number of Words:

    2147483648 words

  • Number of Words Code:

    2000000000

  • Operating Mode:

    SYNCHRONOUS

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Organization:

    2GX1

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TBGA

  • Package Shape:

    RECTANGULAR

  • Package Style:

    GRID ARRAY, THIN PROFILE

  • Parallel/Serial:

    SERIAL

  • Peak Reflow Temperature (Cel):

    260

  • Programming Voltage:

    1.8 V

  • Seated Height-Max:

    1.2 mm

  • Supply Voltage-Max (Vsup):

    2 V

  • Supply Voltage-Min (Vsup):

    1.7 V

  • Supply Voltage-Nom (Vsup):

    1.8 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Tin/Silver/Copper (Sn/Ag/Cu)

  • Terminal Form:

    BALL

  • Terminal Pitch:

    1 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    6 mm

MT35XU02GCBA1G12-0SIT Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the MT35XU02GCBA1G12-0SIT is 0°C to 95°C.
  • To ensure signal integrity on the memory bus, it is recommended to use a controlled impedance PCB, route signals as differential pairs, and use terminations and series resistors as needed.
  • The recommended refresh rate for the MT35XU02GCBA1G12-0SIT is 2x refresh per second at 85°C and 1x refresh per second at 95°C.
  • No, the MT35XU02GCBA1G12-0SIT is designed to operate at a voltage supply of 1.2V, and using it with a different voltage supply may damage the device or affect its performance.
  • Error handling and retries should be implemented in the system's memory controller or processor, and may involve features such as ECC, parity checking, and retry mechanisms.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

MT35XU02GCBA1G12-0SIT Overview

Use the download button to access the MT35XU02GCBA1G12-0SIT schematic symbol, PCB footprint, and 3D model.
