MT4LC4M16R6TG-5 - Micron

MT4LC4M16R6TG-5 Details

• Manufacturer Part Number:

  MT4LC4M16R6TG-5

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TSOP

• Package Description:

  0.400 INCH, PLASTIC, TSOP-50

• Pin Count:

  50

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.02

• Manufacturer:

  Micron Technology Inc

• YTEOL:

  0

• Access Mode:

  FAST PAGE WITH EDO

• Access Time-Max:

  50 ns

• Additional Feature:

  RAS ONLY/CAS BEFORE RAS/HIDDEN REFRESH

• I/O Type:

  COMMON

• JESD-30 Code:

  R-PDSO-G50

• JESD-609 Code:

  e0

• Length:

  20.95 mm

• Memory Density:

  67108864 bit

• Memory IC Type:

  EDO DRAM

• Memory Width:

  16

• Number of Functions:

  1

• Number of Ports:

  1

• Number of Terminals:

  50

• Number of Words:

  4194304 words

• Number of Words Code:

  4000000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  70 °C

• Organization:

  4MX16

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSOP2

• Package Equivalence Code:

  TSOP50,.46,32

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, THIN PROFILE

• Peak Reflow Temperature (Cel):

  235

• Qualification Status:

  Not Qualified

• Refresh Cycles:

  4096

• Seated Height-Max:

  1.2 mm

• Self Refresh:

  NO

• Standby Current-Max:

  0.0005 A

• Supply Current-Max:

  0.15 mA

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  3 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  10.16 mm
