MTX2-73+ - Mini-Circuits

Description: Signal Conditioning MMIC TRANSFORMER/ RoHS

Download MTX2-73+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MTX2-73+ - Mini-Circuits PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - DQ1225_2021
click to zoom
3D Models
MTX2-73+ - Mini-Circuits  - 3D model - Quad Flat No-Lead - DQ1225_2021
click to zoom

MTX2-73+ Details

  • Manufacturer Part Number:

    MTX2-73+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    7

  • Cut-off Frequency-Min:

    2000 MHz

  • Height:

    0.89 mm

  • Insertion Loss:

    2.3 dB

  • Length:

    3 mm

  • Mounting Feature:

    SURFACE MOUNT

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Packing Method:

    TR, 7 INCH

  • Surface Mount:

    YES

  • Transformer Type:

    RF TRANSFORMER

  • Width:

    3 mm

MTX2-73+ Frequently Asked Questions (FAQs)

  • The maximum operating temperature for the MTX2-73+ is 85°C (185°F).
  • Yes, the MTX2-73+ is designed to operate in humid environments, but it's recommended to follow proper storage and handling procedures to prevent moisture damage.
  • Mini-Circuits recommends a 4-layer PCB with a solid ground plane and a 50-ohm microstrip transmission line for optimal performance.
  • Yes, the MTX2-73+ is designed to withstand moderate vibration, but it's recommended to follow proper mounting and securing procedures to prevent mechanical stress.
  • The typical current consumption of the MTX2-73+ is 30-40 mA, depending on the operating frequency and input power level.
