MUBW20-06A6K - LITTELFUSE

MUBW20-06A6K Details

• Manufacturer Part Number:

  MUBW20-06A6K

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  0

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  12 A

• Collector-Emitter Voltage-Max:

  600 V

• Configuration:

  COMPLEX

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-XUFM-X25

• Number of Elements:

  7

• Number of Terminals:

  25

• Operating Temperature-Max:

  125 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  85 W

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Finish:

  Pure Tin (Sn)

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  165 ns

• Turn-on Time-Nom (ton):

  30 ns

• VCEsat-Max:

  2.4 V
