MUR5U60-TP - MCC

MUR5U60-TP Details

• Manufacturer Part Number:

  MUR5U60-TP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China, Vietnam

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  Micro Commercial Components

• YTEOL:

  6

• Application:

  EFFICIENCY

• Breakdown Voltage-Min:

  600 V

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.5 V

• JEDEC-95 Code:

  TO-277

• JESD-30 Code:

  R-PDSO-F3

• Non-rep Pk Forward Current-Max:

  120 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR

• Rep Pk Reverse Voltage-Max:

  600 V

• Reverse Current-Max:

  5 µA

• Reverse Recovery Time-Max:

  0.05 µs

• Reverse Test Voltage:

  600 V

• Surface Mount:

  YES

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL
