MYMGC0R88RFLF2RV - Murata Electronics

MYMGC0R88RFLF2RV Details

• Manufacturer Part Number:

  MYMGC0R88RFLF2RV

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Factory Lead Time:

  46 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CSA, EN, IEC, UL

• Efficiency (Main Output):

  81%

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  3.3 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-XBGA-N60

• Length:

  15 mm

• Line Regulation-Max:

  1%

• Load Regulation-Max:

  1%

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  60

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  8 A

• Output Voltage-Max:

  0.8585 V

• Output Voltage-Min:

  0.8415 V

• Output Voltage-Nom:

  0.85 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  BGA

• Package Equivalence Code:

  LGA60(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY

• Protections:

  OVER CURRENT, SHORT CIRCUIT, UNDER VOLTAGE

• Ripple Voltage (Main Out):

  0.00707 Vrms

• Seated Height-Max:

  2.4 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM

• Total Power Output-Max:

  6.8 W

• Trim/Adjustable Output:

  NO

• Width:

  11.9 mm
