MYMGC3R32EFPF2RB - Murata Electronics

MYMGC3R32EFPF2RB Details

• Manufacturer Part Number:

  MYMGC3R32EFPF2RB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Factory Lead Time:

  62 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  7

• Additional Feature:

  1.2V, 1.8V, 2.5V ADDITIONAL OUTPUT AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  88%

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  4.3 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-XXMA-N

• Length:

  15 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  1%

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Outputs:

  4

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  2.5 A

• Output Voltage-Max:

  3.366 V

• Output Voltage-Min:

  3.234 V

• Output Voltage-Nom:

  3.3 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Equivalence Code:

  LCC61,.5X.6(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  245

• Protections:

  OVER CURRENT, OVER VOLTAGE, UNDER VOLTAGE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.00707 Vrms

• Seated Height-Max:

  2.4 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Form:

  NO LEAD

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  15.15 W

• Trim/Adjustable Output:

  YES

• Width:

  11.4 mm
