NC7WB66L8X - onsemi

Description: Analog Switch ICs Low Voltage UHS Dual SPST Normally

Download NC7WB66L8X Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NC7WB66L8X - onsemi PCB footprint - Other - Other - NC7WB66L8X-1
click to zoom
3D Models
NC7WB66L8X - onsemi  - 3D model - Other - NC7WB66L8X-1
click to zoom

NC7WB66L8X Details

  • Manufacturer Part Number:

    NC7WB66L8X

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    1.60 MM, MICROPAK-8

  • Manufacturer Package Code:

    523AY

  • Country Of Origin:

    Thailand

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    onsemi

  • YTEOL:

    0

  • Analog IC - Other Type:

    SPST

  • JESD-30 Code:

    S-XQCC-N8

  • JESD-609 Code:

    e4

  • Length:

    1.6 mm

  • Moisture Sensitivity Level:

    1

  • Normal Position:

    NO

  • Number of Channels:

    1

  • Number of Functions:

    2

  • Number of Terminals:

    8

  • Off-state Isolation-Nom:

    55 dB

  • On-state Resistance Match-Nom:

    0.5 Ω

  • On-state Resistance-Max (Ron):

    20 Ω

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    SEPARATE OUTPUT

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    VQCCN

  • Package Equivalence Code:

    LCC8,.06SQ,20

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    0.55 mm

  • Signal Current-Max:

    0.128 A

  • Supply Current-Max (Isup):

    100 mA

  • Supply Voltage-Max (Vsup):

    5.5 V

  • Supply Voltage-Min (Vsup):

    1.65 V

  • Supply Voltage-Nom (Vsup):

    2.3 V

  • Surface Mount:

    YES

  • Switch-off Time-Max:

    6.9 ns

  • Switch-on Time-Max:

    5.6 ns

  • Switching:

    BREAK-BEFORE-MAKE

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    1.6 mm

NC7WB66L8X Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the NC7WB66L8X is 1.65V to 5.5V.
  • To properly power down the NC7WB66L8X, ensure that the VCC pin is connected to a stable power source, and the EN pin is pulled low to disable the device.
  • The NC7WB66L8X supports data transfer rates up to 50 Mbps.
  • To handle clock skew and jitter, ensure that the clock signal is properly terminated, and the clock frequency is within the recommended range. Additionally, consider using a clock buffer or jitter attenuator if necessary.
  • The NC7WB66L8X can drive capacitive loads up to 50 pF.
