NCP1850FCCT1G - onsemi

NCP1850FCCT1G Details

• Manufacturer Part Number:

  NCP1850FCCT1G

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  WLCSP25, 2.06x2.06

• Package Description:

  WLCSP-25

• Pin Count:

  25

• Manufacturer Package Code:

  567FZ

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  4 Weeks

• Manufacturer:

  onsemi

• YTEOL:

  0

• Additional Feature:

  Thermal Shutdown:140C

• Adjustable Threshold:

  NO

• Analog IC - Other Type:

  LINEAR BATTERY CHARGER

• JESD-30 Code:

  S-PBGA-B25

• Length:

  2.06 mm

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Terminals:

  25

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Seated Height-Max:

  0.6 mm

• Supply Voltage-Max (Vsup):

  7 V

• Supply Voltage-Min (Vsup):

  3.6 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Threshold Voltage-Nom:

  +3.6V

• Width:

  2.06 mm
