NCP45495XMNTWG - onsemi

Description: 4-Channel Voltage Bus and 4-Channel High-Side Current Shunt Monitor, 26 V

Download NCP45495XMNTWG Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NCP45495XMNTWG - onsemi PCB footprint - Other - Other - NCP45495XMNTWG-3
click to zoom
3D Models
NCP45495XMNTWG - onsemi  - 3D model - Other - NCP45495XMNTWG-3
click to zoom

NCP45495XMNTWG Details

  • Manufacturer Part Number:

    NCP45495XMNTWG

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    QFN-32

  • Manufacturer Package Code:

    485CD

  • Country Of Origin:

    Taiwan, Thailand

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    20 Weeks

  • Manufacturer:

    onsemi

  • YTEOL:

    6

  • Adjustable Threshold:

    YES

  • Analog IC - Other Type:

    HIGH SIDE POWER/CURRENT MONITOR

  • JESD-30 Code:

    S-XQCC-N32

  • JESD-609 Code:

    e3

  • Length:

    4 mm

  • Moisture Sensitivity Level:

    1

  • Number of Channels:

    4

  • Number of Functions:

    1

  • Number of Terminals:

    32

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    HVQCCN

  • Package Equivalence Code:

    LCC32,.16SQ,16

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1 mm

  • Supply Current-Max (Isup):

    2 mA

  • Supply Voltage-Max (Vsup):

    3.8 V

  • Supply Voltage-Min (Vsup):

    2.8 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.4 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    4 mm

NCP45495XMNTWG Frequently Asked Questions (FAQs)

  • A thermal pad is recommended under the package to improve thermal performance. A minimum of 2oz copper thickness and a thermal relief pattern are recommended. Refer to the onsemi application note AND9407/D for more details.
  • Ensure that the input voltage rises monotonically during start-up and falls monotonically during shutdown. A soft-start circuit can be used to control the input voltage rise time. A minimum input voltage of 2.5V is recommended for reliable start-up.
  • The maximum allowed input voltage ripple is 10% of the nominal input voltage. Exceeding this limit may affect the device's performance and reliability.
  • Yes, the device is rated for operation up to 150°C junction temperature. However, the maximum operating temperature is dependent on the specific application and thermal design. Ensure that the device is properly cooled and the thermal design is validated for the specific application.
  • Check the input voltage, output current, and sense resistor values. Ensure that the sense resistor is properly connected and the current sense pin is not overloaded. Verify that the overcurrent protection threshold is set correctly. Refer to the datasheet and application notes for more details.
