NCP45790IMN24RTWG - onsemi

Description: Dual Integrated N-Channel MOSFETs; Ultra-Low On-Resistance; Soft-Start via Slew Rate Control; Reverse Current Protection; Advanced Controller with Charge Pump; Input Voltage Range 2 V to 24 V (30V Tolerant); Low Standby Current; No External Components Required; Enable Pins with CMOS Input Levels; Power Good Signaling; Fault Protection: Over Temperature; Fault Protection: Under Voltage Lockout; Fault Protection: Short-Circuit Protection; Fault Protection: Over Current Protection; Pb-Free Device

Download NCP45790IMN24RTWG Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
NCP45790IMN24RTWG - onsemi - PCB symbol
click to zoom
PCB Footprints
NCP45790IMN24RTWG - onsemi PCB footprint - Other - Other - DFN14 4x4, 0.5P CASE 506EK ISSUE A
click to zoom
3D Models
NCP45790IMN24RTWG - onsemi - 3D model - Other - DFN14 4x4, 0.5P CASE 506EK ISSUE A
click to zoom

NCP45790IMN24RTWG Details

  • Manufacturer Part Number:

    NCP45790IMN24RTWG

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    DFN-14

  • Manufacturer Package Code:

    506EK

  • Country Of Origin:

    Thailand

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2018-12-12

  • Manufacturer:

    onsemi

  • YTEOL:

    7.13

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    Load switch

  • JESD-30 Code:

    S-PDSO-N14

  • Length:

    4 mm

  • Moisture Sensitivity Level:

    3

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Equivalence Code:

    SOLCC14,.16,20

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1 mm

  • Supply Voltage-Max (Vsup):

    5.5 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    4 mm

NCP45790IMN24RTWG Frequently Asked Questions (FAQs)

  • A 2-layer or 4-layer PCB with a solid ground plane and thermal vias is recommended. The device should be placed near a thermal pad or heat sink to dissipate heat efficiently.
  • Ensure proper thermal design, use a heat sink if necessary, and follow the recommended operating conditions. Also, consider using a thermal interface material to improve heat transfer.
  • Exceeding the maximum Tj rating can lead to reduced lifespan, decreased performance, and potentially catastrophic failure. It's essential to ensure the device operates within the recommended temperature range.
  • Yes, the device is suitable for high-reliability and automotive applications. However, it's essential to follow the recommended operating conditions, and ensure the device is properly qualified and validated for the specific application.
  • Consult the datasheet and application notes for troubleshooting guidelines. Check for proper PCB layout, thermal design, and component selection. Also, verify that the device is operated within the recommended conditions and that the input voltage and current are within specifications.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

NCP45790IMN24RTWG Overview

Use the download button to access the NCP45790IMN24RTWG schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like NCP45, or try a keyword search, such as Power Management Circuits
