NCV59748ML075TBG - onsemi

NCV59748ML075TBG Details

• Manufacturer Part Number:

  NCV59748ML075TBG

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  DFNW-10

• Package Description:

  DFNW-10

• Manufacturer Package Code:

  507AE

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Date Of Intro:

  2019-10-03

• Manufacturer:

  onsemi

• YTEOL:

  7.7

• Adjustability:

  FIXED

• Dropout Voltage1-Max:

  0.165 V

• Dropout Voltage1-Nom:

  0.06 V

• Input Voltage Absolute-Max:

  6 V

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  0.915 V

• JESD-30 Code:

  S-XDSO-N10

• Length:

  3 mm

• Line Regulation-Max:

  0.001031625%

• Load Regulation-Max:

  0.000675%

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  10

• Operating Temperature TJ-Max:

  125 °C

• Operating Temperature TJ-Min:

  -40 °C

• Output Current1-Max:

  1.5 A

• Output Voltage1-Max:

  0.765 V

• Output Voltage1-Min:

  0.735 V

• Output Voltage1-Nom:

  0.75 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC10,.11,20

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TR

• Peak Reflow Temperature (Cel):

  260

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  1 mm

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Voltage Tolerance-Max:

  2%

• Width:

  3 mm
