NFAL3512L5BT - onsemi

NFAL3512L5BT Details

• Manufacturer Part Number:

  NFAL3512L5BT

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DIP31, 79x30/SPM49 CAB

• Manufacturer Package Code:

  MODGQ

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Date Of Intro:

  2020-04-03

• Manufacturer:

  onsemi

• YTEOL:

  0

• Analog IC - Other Type:

  TRACTION INVERTER

• JESD-30 Code:

  R-XDFM-T31

• Number of Functions:

  1

• Number of Terminals:

  31

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  70 A

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Supply Current-Max (Isup):

  6.5 mA

• Supply Voltage-Max (Vsup):

  16.5 V

• Supply Voltage-Min (Vsup):

  13.5 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL
