NFAL5065L4BT - onsemi

Description: Motor / Motion / Ignition Controllers & Drivers SPM49 650V 50A

Download NFAL5065L4BT Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
3D Models
NFAL5065L4BT - onsemi  - 3D model
click to zoom
Note! To download footprints and symbols, use the build and request forms below

Build

Launch Build Wizard
Build Wizard not available for this package category!

Request (48 hours)

NFAL5065L4BT Details

  • Manufacturer Part Number:

    NFAL5065L4BT

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    DIP31, 79x30/SPM49 CAB

  • Package Description:

    DMA,

  • Manufacturer Package Code:

    MODGQ

  • Reach Compliance Code:

    Not Compliant

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    8 Weeks

  • Date Of Intro:

    2019-04-05

  • Manufacturer:

    onsemi

  • YTEOL:

    9.6

  • Additional Feature:

    CONTROL SUPPLY VOLTAGE= 15V

  • Analog IC - Other Type:

    AC MOTOR CONTROLLER

  • JESD-30 Code:

    R-XDMA-T31

  • JESD-609 Code:

    e3

  • Length:

    79 mm

  • Number of Functions:

    1

  • Number of Terminals:

    31

  • Output Current-Max:

    100 A

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    DMA

  • Package Shape:

    RECTANGULAR

  • Package Style:

    MICROELECTRONIC ASSEMBLY

  • Seated Height-Max:

    8.8 mm

  • Supply Voltage-Max (Vsup):

    400 V

  • Supply Voltage-Nom (Vsup):

    300 V

  • Surface Mount:

    NO

  • Technology:

    HYBRID

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Position:

    DUAL

  • Width:

    31 mm

NFAL5065L4BT Frequently Asked Questions (FAQs)

  • A good PCB layout for optimal thermal performance involves placing thermal vias under the IC, using a solid ground plane, and keeping the thermal path as short as possible. A 4-layer PCB with a dedicated thermal layer is recommended.
  • To ensure reliable operation at high temperatures, it's essential to follow the recommended thermal design guidelines, use a suitable heat sink, and ensure good airflow around the device. Additionally, consider derating the device's power handling capabilities at higher temperatures.
  • Although the datasheet doesn't specify a maximum voltage for the enable pin (EN), it's recommended to keep it within the VCC voltage range (typically 5V or 3.3V) to ensure reliable operation and prevent damage to the device.
  • Yes, the NFAL5065L4BT is suitable for high-frequency switching applications. However, it's essential to consider the device's switching losses, ensure proper PCB layout, and follow the recommended operating conditions to minimize electromagnetic interference (EMI) and ensure reliable operation.
  • To troubleshoot OCP issues, check the device's datasheet for the OCP threshold and response time. Verify that the sense resistor (Rs) is correctly sized and connected. Also, ensure that the device is properly powered and that the input voltage is within the recommended range.

Trust Checks

No trust score is available for this model.
Trust Score Unavailable
Sponsored

NFAL5065L4BT Overview

Use the download button to access the NFAL5065L4BT 3D model. You can still request or build the schematic symbol and PCB footprint by using the respective build or request forms on this page.
To find more CAD model downloads similar to this part, try a partial part number search, like NFAL5, or try a keyword search, such as Motion Control Electronics
