NJG1815K75-TE1 - Nisshinbo

Description: RF Switch ICs SPDT Switch GaAs 1.8V 3.3V .45dB

Download NJG1815K75-TE1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NJG1815K75-TE1 - Nisshinbo PCB footprint - Other - Other - NJG1815K75-TE1-1
click to zoom
3D Models
NJG1815K75-TE1 - Nisshinbo  - 3D model - Other - NJG1815K75-TE1-1
click to zoom

NJG1815K75-TE1 Details

  • Manufacturer Part Number:

    NJG1815K75-TE1

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.50.70.00

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Nisshinbo Micro Devices

  • JESD-609 Code:

    e4

  • RF/Microwave Device Type:

    DIVERSITY SWITCH

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)
