NJM2761V - Nisshinbo

NJM2761V Details

• Manufacturer Part Number:

  NJM2761V

• Part Life Cycle Code:

  Active

• Package Description:

  SSOP-14

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Nisshinbo Micro Devices

• Consumer IC Type:

  CONSUMER CIRCUIT

• JESD-30 Code:

  R-PDSO-G14

• Length:

  5 mm

• Number of Functions:

  1

• Number of Terminals:

  14

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -20 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LSSOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.45 mm

• Supply Voltage-Max (Vsup):

  13 V

• Supply Voltage-Min (Vsup):

  2.7 V

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Width:

  4.4 mm
