The recommended land pattern for NL565050T-103J-PF can be found in the TDK Corporation's application note or the IPC-7351 standard. It's essential to follow the recommended land pattern to ensure reliable soldering and prevent defects.
Handle the NL565050T-103J-PF by the edges or the recommended handling areas to prevent damage to the component. Avoid touching the component's terminals or the ceramic body to prevent electrostatic discharge (ESD) damage.
The maximum allowable voltage derating for NL565050T-103J-PF is typically 80% of the rated voltage. However, it's recommended to consult with TDK Corporation or a qualified engineer to determine the appropriate derating for your specific application.
The NL565050T-103J-PF is rated for operation up to 125°C. However, it's essential to consider the component's temperature coefficient and the application's specific requirements. Consult with TDK Corporation or a qualified engineer to determine the component's suitability for your high-temperature application.
The recommended soldering profile for NL565050T-103J-PF follows the IPC-J-STD-020 standard. A typical profile includes a peak temperature of 245°C, a dwell time above 217°C of 20-40 seconds, and a cooling rate of 4°C/s max.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
NL565050T-103J-PF Overview
Use the download button to access the NL565050T-103J-PF schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like NL565,
or try a keyword search, such as Fixed Inductors
