NR1641ZA330CE2S - Nisshinbo

NR1641ZA330CE2S Details

• Manufacturer Part Number:

  NR1641ZA330CE2S

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Nisshinbo Micro Devices

• YTEOL:

  7

• Adjustability:

  FIXED

• Dropout Voltage1-Nom:

  0.5 V

• Input Voltage Absolute-Max:

  6.5 V

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  3.8 V

• JESD-30 Code:

  R-XBGA-B6

• JESD-609 Code:

  e1

• Length:

  1.3 mm

• Load Regulation-Max(%):

  0.0165%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature TJ-Max:

  125 °C

• Operating Temperature TJ-Min:

  -40 °C

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current1-Max:

  1 A

• Output Voltage1-Max:

  3.39 V

• Output Voltage1-Min:

  3.21 V

• Output Voltage1-Nom:

  3.3 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA6(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Packing Method:

  TR

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Terminal Form:

  BALL

• Terminal Position:

  BOTTOM

• Voltage Tolerance-Max:

  2.7%

• Width:

  0.88 mm
