NRS5040T100MMGJ8 - TAIYO YUDEN

NRS5040T100MMGJ8 Details

• Manufacturer Part Number:

  NRS5040T100MMGJ8

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  7 Weeks

• Manufacturer:

  TAIYO YUDEN

• YTEOL:

  7

• Case/Size Code:

  1919

• Construction:

  Rectangular

• DC Resistance:

  0.056 Ω

• Inductance-Nom (L):

  10 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  4 mm

• Package Length:

  4.9 mm

• Package Style:

  SMT

• Package Width:

  4.9 mm

• Packing Method:

  TR, Embossed , 13 Inch

• Rated Current-Max:

  2.1 A

• Reference Standard:

  AEC-Q200

• Self Resonance Frequency:

  18 MHz

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  YES

• Special Feature:

  DC RESISTANCE IS MEASURED AT: 30%

• Surface Mount:

  YES

• Terminal Placement:

  DUAL ENDED

• Terminal Shape:

  ONE SURFACE

• Test Frequency:

  0.1 MHz

• Tolerance:

  20%
