NRVHP8H200MFDWFT1G - onsemi

NRVHP8H200MFDWFT1G Details

• Manufacturer Part Number:

  NRVHP8H200MFDWFT1G

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SO-8FL Dual / DFN-8

• Package Description:

  SO8FL, DFN8, 8 PIN

• Manufacturer Package Code:

  506BT

• Country Of Origin:

  Malaysia

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  onsemi

• YTEOL:

  0

• Additional Feature:

  FREE WHEELING DIODE

• Application:

  ULTRA FAST RECOVERY POWER

• Breakdown Voltage-Min:

  200 V

• Case Connection:

  CATHODE

• Configuration:

  SEPARATE, 2 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  0.91 V

• JESD-30 Code:

  R-PDSO-F6

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Pk Forward Current-Max:

  80 A

• Number of Elements:

  2

• Number of Phases:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  4 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Reference Standard:

  AEC-Q101

• Rep Pk Reverse Voltage-Max:

  200 V

• Reverse Current-Max:

  0.5 µA

• Reverse Recovery Time-Max:

  0.03 µs

• Reverse Test Voltage:

  200 V

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30
