NSC800V-4I - Texas Instruments

NSC800V-4I Details

• Manufacturer Part Number:

  NSC800V-4I

• Rohs Code:

  No

• Part Life Cycle Code:

  Obsolete

• Package Description:

  QCCJ, LDCC(UNSPEC)

• Reach Compliance Code:

  Unknown

• HTS Code:

  8542.31.00.15

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Address Bus Width:

  16

• Bit Size:

  8

• Boundary Scan:

  NO

• Clock Frequency-Max:

  8 MHz

• External Data Bus Width:

  8

• Format:

  FIXED POINT

• Integrated Cache:

  NO

• JESD-30 Code:

  S-PQCC-J44

• JESD-609 Code:

  e0

• Length:

  16.51 mm

• Low Power Mode:

  YES

• Number of External Interrupts:

  5

• Number of Terminals:

  44

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QCCJ

• Package Equivalence Code:

  LDCC(UNSPEC)

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Qualification Status:

  Not Qualified

• RAM (words):

  0

• Seated Height-Max:

  4.57 mm

• Speed:

  4 MHz

• Supply Current-Max:

  21 mA

• Supply Voltage-Max:

  6 V

• Supply Voltage-Min:

  2.4 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  J BEND

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  QUAD

• Width:

  16.51 mm

• uPs/uCs/Peripheral ICs Type:

  MICROPROCESSOR
