NSJ12HF-1 - Neutrik

NSJ12HF-1 Details

• Manufacturer Part Number:

  NSJ12HF-1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Neutrik USA Inc

• YTEOL:

  7

• Audio Type:

  STEREO

• Body Breadth:

  1.25 inch

• Body Depth:

  1.296 inch

• Body Length:

  0.669 inch

• Body/Shell Style:

  JACK

• Connector Type:

  6.3MM AUDIO

• Contact Finish Mating:

  AG

• Contact Gender:

  FEMALE

• Contact Material:

  BRONZE

• Contact Resistance:

  15 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  1000VDC V

• Durability:

  1000 Cycles

• Insertion Force-Max:

  20.016 N

• Insulation Resistance:

  1000000000 Ω

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Poles:

  2

• Number of Ports:

  1

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Plating Thickness:

  79u inch

• Polarization Key:

  POLARIZED KEY

• Rated Current (Signal):

  3 A

• Terminal Length:

  0.13 inch

• Termination Type:

  SOLDER

• Withdrawl Force-Min:

  9.7856 N
