NTTFSSH0D7N02X - onsemi

NTTFSSH0D7N02X Details

• Manufacturer Part Number:

  NTTFSSH0D7N02X

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  WDFN-9

• ECCN Code:

  EAR99

• Manufacturer:

  onsemi

• YTEOL:

  5

• Avalanche Energy Rating (Eas):

  192 mJ

• Case Connection:

  SOURCE

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  25 V

• Drain Current-Max (ID):

  310 A

• Drain-source On Resistance-Max:

  0.00058 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  124 pF

• JESD-30 Code:

  S-PTSO-N9

• Number of Elements:

  1

• Number of Terminals:

  9

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  87 W

• Pulsed Drain Current-Max (IDM):

  1342 A

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Position:

  TRIPLE

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
