NVMJST1D2N04CTXG - onsemi

Description: N-Channel 40 V 451A (Tc) 454W (Tc) Surface Mount 10-TCPAK 4V @ 200µA 82 nC @ 10 V -55°C ~ 175°C 454W

Download NVMJST1D2N04CTXG Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NVMJST1D2N04CTXG - onsemi PCB footprint - Other - Other - TCPAK10 5.1x7.5, 1.0P CASE 760AG ISSUE D_2025
click to zoom
3D Models
NVMJST1D2N04CTXG - onsemi  - 3D model - Other - TCPAK10 5.1x7.5, 1.0P CASE 760AG ISSUE D_2025
click to zoom

NVMJST1D2N04CTXG Details

  • Manufacturer Part Number:

    NVMJST1D2N04CTXG

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    TCPAK10 5.1x7.5, 1.0P

  • Manufacturer Package Code:

    760AG

  • Country Of Origin:

    Mainland China, Malaysia, Philippines, Thailand, Vietnam

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    13 Weeks

  • Manufacturer:

    onsemi

  • YTEOL:

    6

  • Avalanche Energy Rating (Eas):

    1541 mJ

  • Case Connection:

    DRAIN

  • Configuration:

    SINGLE WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    40 V

  • Drain Current-Max (ID):

    451 A

  • Drain-source On Resistance-Max:

    0.00125 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • Feedback Cap-Max (Crss):

    140 pF

  • JESD-30 Code:

    R-PDSO-G10

  • JESD-609 Code:

    e4

  • Moisture Sensitivity Level:

    1

  • Number of Elements:

    1

  • Number of Terminals:

    10

  • Operating Mode:

    ENHANCEMENT MODE

  • Operating Temperature-Max:

    175 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Polarity/Channel Type:

    N-CHANNEL

  • Power Dissipation-Max (Abs):

    454 W

  • Pulsed Drain Current-Max (IDM):

    900 A

  • Reference Standard:

    AEC-Q101

  • Surface Mount:

    YES

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Transistor Element Material:

    SILICON
