NVXK2VR80WDT2 - onsemi

NVXK2VR80WDT2 Details

• Manufacturer Part Number:

  NVXK2VR80WDT2

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  APM32 44.00x28.80x5.70

• Manufacturer Package Code:

  MODHM

• ECCN Code:

  EAR99

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  onsemi

• YTEOL:

  7

• Avalanche Energy Rating (Eas):

  180 mJ

• Configuration:

  3 BANKS, SERIES CONNECTED, CENTER TAP, 2 ELEMENTS WITH BUILT-IN DIODE AND THERMISTOR

• DS Breakdown Voltage-Min:

  1200 V

• Drain Current-Max (ID):

  20 A

• Drain-source On Resistance-Max:

  0.116 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  7.9 pF

• JESD-30 Code:

  R-PDIP-T32

• JESD-609 Code:

  e3

• Number of Elements:

  6

• Number of Terminals:

  32

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  82 W

• Pulsed Drain Current-Max (IDM):

  96 A

• Reference Standard:

  AEC-Q101; IEC-60664-1; IEC-60950-1

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Transistor Element Material:

  SILICON CARBIDE
