NXV08H350XT1 - onsemi

NXV08H350XT1 Details

• Manufacturer Part Number:

  NXV08H350XT1

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  APM17−MDC

• Manufacturer Package Code:

  MODHH

• ECCN Code:

  EAR99

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  onsemi

• YTEOL:

  6

• Avalanche Energy Rating (Eas):

  1946 mJ

• Case Connection:

  ISOLATED

• Configuration:

  COMPLEX

• DS Breakdown Voltage-Min:

  80 V

• Drain-source On Resistance-Max:

  0.001039 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  53 pF

• JESD-30 Code:

  R-PDIP-T17

• JESD-609 Code:

  e3

• Number of Elements:

  4

• Number of Terminals:

  17

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  N-CHANNEL

• Reference Standard:

  AEC-Q101

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Element Material:

  SILICON
